Death by a (Few) Thousands of Threads 👻

There are things in life that excites and scares you at the same time. Recently I helped out a case when it’s both exciting and scary. The problem was a gigantic 106 GB memory dump with a very small managed heap compared to the dump’s size. That hints unmanaged memory leak. While I’m fairly confident with memory dump analysis, I haven’t had a lot of good luck with unmanaged memory leaks. It could have turned into a big headache and unknown territory. But if it’s not me then who will go to hell? Then game is on.

The Unmanaged Mystery

As we said, the actual memory dump is 106GB insize. The actual managed heap was only about 750 MB. When you have a big memory dump that also has a big heap, you likely have some dominant object types. But if you have a (very) small heap, it means a lot of memory is allocated as unmanaged, which can be, most of the time, very tricky to figure out.

The heap statistics looked like this:

7644edfba450    87,127   4,895,256 System.String[]
7644f0b1b718    88,507   4,956,392 EPiServer.Core.PropertyBoolean
7644f77fb8d8    81,056   5,187,584 Microsoft.Extensions.Caching.Memory.PostEvictionDelegate
7644fa376d60    73,994   5,327,568 System.Collections.Concurrent.ConcurrentDictionary<EPiServer.Core.Internal.ContentCacheKeyLookup+KeyLookup, System.String>+Node
7644f0b16f30    83,480   5,342,720 EPiServer.Core.PropertyString
7644f88e8020     1,622   6,526,928 Microsoft.ApplicationInsights.Channel.ITelemetry[]
7644fa3b5390    31,727   7,371,552 EPiServer.Core.PropertyData[]
7644f4ffd310    82,950   8,626,800 Microsoft.Extensions.Caching.Memory.CacheEntry
7644eeb43710    88,044   9,156,576 System.Reflection.RuntimeMethodInfo
7644edea89e0   109,744  10,730,392 System.Int32[]
7644fa730e58    30,460  23,308,416 System.Collections.Generic.Dictionary<System.String, EPiServer.Core.PropertyData>+Entry[]
7644f0b12b90   317,446  25,395,680 EPiServer.Core.PropertyLongString
7644eeb8c418    90,688  58,585,762 System.Byte[]
7644edead7c8 1,051,306 148,543,168 System.String
62efedb200b0    90,833 213,897,448 Free
Total 5,623,983 objects, 763,492,663 bytes

Then where is the rest? When I was about to pull the hairs (whatever I have left), I realized I don’t have to. Something else caught I attention. Before diving into the scary unmanaged memory part, maybe it’s worth checking this first.

The Thread Bomb

The silver lining was this: multiple threads stuck at the same stack trace. In a smaller dump, there were 1,647 threads with 1,600 of them in the same stack trace. In the big one, there were 13,000! Yes, you read that right, thirteen thousands. And most of them were in this same stack trace:

00007603C3FFE8B0 000076456c8bcf16 [HelperMethodFrame: 00007603c3ffe8b0] System.Threading.WaitHandle.WaitOneCore(IntPtr, Int32)
00007603C3FFE9E0 00007644fd999020 System.Threading.WaitHandle.WaitOneNoCheck(Int32) [/*/src/libraries/System.Private.CoreLib/src/System/Threading/WaitHandle.cs @ 128]
00007603C3FFEA20 00007644f872440a **Microsoft.ApplicationInsights.Channel.InMemoryTransmitter.Runner()**
00007603C3FFEAB0 00007644fb42db75 System.Threading.ExecutionContext.RunInternal(System.Threading.ExecutionContext, System.Threading.ContextCallback, System.Object) [/*/src/libraries/System.Private.CoreLib/src/System/Threading/ExecutionContext.cs @ 179]
00007603C3FFEB10 00007644fb4810aa System.Threading.Tasks.Task.ExecuteWithThreadLocal(System.Threading.Tasks.Task ByRef, System.Threading.Thread) [/\_/src/libraries/System.Private.CoreLib/src/System/Threading/Tasks/Task.cs @ 2345]
00007603C3FFECD0 000076456c542c37 [DebuggerU2MCatchHandlerFrame: 00007603c3ffecd0]

The trace clearly suggests this has something to do with Application Insights telemetry. I turned to CoPilot to get a better understanding—it is surprisingly good at that. And here is what it suggested:

✅ What You Should Check

If you’re seeing many such threads or suspect a leak:

• Ensure TelemetryClient is reused (singleton pattern)
• Call Flush() and allow time for transmission on shutdown
• Avoid creating multiple InMemoryChannel instances

Hmm, then maybe I should check how many TelemetryClient instances there are.

The Silent Killer: Missing Configuration

There were several places that created an instance of TelemetryConfiguration with .CreateDefault(). This creates an instance of TelemetryConfiguration with the default setting found in ApplicationInsights.config. What if such a file does not exist? It will create an empty configuration.

An instance that does not have a connection string nor instrumentation key to send to AI. So all the threads are waiting for data to be sent, just nowhere to send it, causing a massive amount of threads and a huge allocation on unmanaged memory (stack space for each thread).

This was confirmed with this debug output:

0:023\> \!do 7604f69db0a0
Name:        Microsoft.ApplicationInsights.Extensibility.TelemetryConfiguration
...
Fields:
...
00007644edead7c8  40000bb       28        System.String  0 instance 00007604e18b3c00 instrumentationKey
00007644edead7c8  40000bc       30        System.String  0 instance **0000000000000000 connectionString**
...
0:023\> \!DumpObj /d 00007604e18b3c00
Name:        System.String
...
String:      325550d4-7bfd-4fbf-a5f8-e253b4120426

The connectionString was null, despite an instrumentation key (which was likely not valid in the context).

The Mechanics of the Leak

Now this is the fun part. Whenever the customer sends a telemetry event to AI, it will be sent async. A new thread will be spawned, either new or from the threadpool, to send the request, and then return to the threadpool waiting to be awakened again.

BUT, and that’s a big but, if there is no configuration, the InMemoryTransmitter does not know where to send the telemetry to. Ending up waiting forever via WaitOneCore. Because it does not return, the next time, the CLR will spawn a new thread, just for it to end up with the same fate.

After a while, you get a few thousands of live threads but doing nothing.

Resolution

It is bad in both ends:

1. The InMemoryTransmitter should have thrown an exception or timed out if it couldn’t send the telemetry.
2. There should be a proper configuration for AI.

The quick solution in this case is to set the ConnectionString properly in code, something like:

_configuration.ConnectionString = Configuration["ApplicationInsights:ConnectionString"];

Moral of story is that you fail to do something, better to throw an exception for it, than just waiting silently
